Technical Specifications
Product Overview
High-Efficiency Residential Heat Pump
This residential swimming pool heat pump provides reliable heating and cooling throughout the year. Featuring a titanium heat exchanger and environmentally friendly R410A refrigerant, the unit ensures long-term durability and corrosion resistance. It includes advanced control features like automatic defrost, high-pressure protection, and MODBUS communication for seamless integration into your pool management system.
Key Features
System Capabilities
- Heating and cooling functionality
- Automatic operation
- Titanium heat exchanger
- Environmentally friendly R410A refrigerant
- Automatic defrost cycle
- High-pressure protection
- MODBUS communication support
- Built-in water flow switch
Performance Data
Standard Performance
| Metric | Heating Capacity | COP |
|---|---|---|
| Air 27°C/24°C, Water 27°C/29°C | 5.0 - 30.0 kW | 5.79 - 6.06 |
| Air 15°C/12°C, Water 26°C/28°C | 3.6 - 23.5 kW | 4.88 - 5.01 |
Technical Specifications
Operating Conditions
-15 °C
Minimum Temp
43 °C
Maximum Temp
50 mm
Water Connection
