Technical Specifications
Product Overview
CZ Series Chemical Process Pump
The CZ series is a horizontal, single-stage, single-suction centrifugal pump engineered for demanding industrial environments. Designed to comply with international standards including DIN24256, ISO2858, and GB5662-85, this unit offers exceptional versatility for handling neutral, corrosive, clean, or particle-laden media. It is an ideal solution for critical applications in chemical engineering, petrochemical processing, power generation, and pharmaceutical manufacturing.
Performance Metrics
Key Operating Metrics
2,400 m3/h
Max Flow Rate
200 m
Max Head
25 bar
Max Pressure
260 °C
Standard Max Temp
Technical Specifications
Operational Conditions
| Parameter | Range/Value |
|---|---|
| Temperature Range | -40°C to 260°C (up to 400°C with special measures) |
| Rotation Speed | 1450 to 3600 rpm |
| Frequency | 50Hz or 60Hz |
| Rotation Direction | Clockwise (viewed from motor) |
Design & Construction
- Foot supporting pump body structure
- Impeller options: closed, semi-open, and fully open
- Thin oil lubrication mode with constant level oil cup
- Shaft protected by bushing to prevent direct medium contact
- Axial force balanced by back blade or balance hole
- Shaft Seal Types
- Packing sealSingle end face mechanical sealDouble end face mechanical sealMechanical seal in series
Applications
Suitable Industries
Chemical EngineeringPetrochemicalsSteel WorksPower PlantsPapermaking & PulpMedicineFood ProcessingSugar Refining
