Sludge Vacuum Pump for Industrial Waste
The sludge vacuum pump is designed for efficient removal of sludge and other viscous materials. It is suitable for the transport of high-density materials, including drilling cuttings and oily sludge.
Technical Specifications
Product Overview
Industrial Sludge Vacuum Pump
This high-performance vacuum pump is designed for the most challenging industrial environments, handling heavy-load materials with ease. It is engineered for durability with virtually no wear parts, making it an ideal solution for transporting drilling cuttings, oily sludge, and high-density industrial waste. Its compact structure ensures suitability for confined spaces while delivering powerful suction capabilities.
Technical Specifications
Performance Metrics
25 inHg
Max Vacuum
80 %
Max Solid Content
1,000 m
Max Delivery Distance
Model Specifications
| Specification | FTSP-10A | FTSP-20A | FTSP-40A |
|---|---|---|---|
| Capacity (m³/h) | 10 | 20 | 40 |
| Connection Size (Inch) | 3 | 3 | 4 |
| Particle Diameter (mm) | <50 | <50 | <75 |
| Gas Pressure (Kpa) | 550-690 | N/A | 550-785 |
Applications
Suitable Applications
- Drilling cuttings removal
- Oily sludge transportation
- Hazardous waste recycling
- Mud pit cleaning
- Bilge clearance of vessels
- Tank bottom slag removal
- Animal droppings management
- Sand and diatomite handling
- Usage Environment
- Heavy DutyIndustrial CleaningEnvironmental RemediationConfined Space Ready
