Single-Toggle Jaw Crusher
This single-toggle jaw crusher features a simple structure and reliable performance. It is designed for easy operation, convenient maintenance, and low equipment and production costs.
Technical Specifications
Overview
High-Efficiency Single-Toggle Jaw Crusher
This advanced compound pendulum jaw crusher is engineered for high reduction ratios and superior yield in primary crushing applications. It features a robust frame construction and a sophisticated hydraulic stepless adjustment system, allowing for flexible control over the discharge mouth size. Designed for reliability and ease of use, this equipment is suitable for processing a wide range of materials in demanding industrial environments.
Technical Specifications
Performance Highlights
1,180 t/h
Max Production Capacity
250 kW
Max Power
Model Specifications
| Model | Feed Port (mm) | Discharge Range (mm) | Power (kW) | Capacity (t/h) |
|---|---|---|---|---|
| HPEF6190 | 609 x 914 | 75-180 | 75 | 120-350 |
| HPEF0710 | 762 x 1067 | 75-180 | 110 | 150-460 |
| HPEF1013 | 1067 x 1372 | 125-250 | 250 | 380-700 |
| HPEF1216 | 1200 x 1600 | 150-300 | 250 | 500-1180 |
Design & Features
Construction Materials
- Heavy-duty steel frame
- High-manganese steel jaw plates
- Key Features
- Hydraulic Stepless AdjustmentCompound Pendulum DesignHigh Reduction RatioHydraulic Overload ProtectionCentralized Lubrication
