Sheet Metal Straightening and Cutting Machine (Up to 2mm)
This straightening and cutting machine processes sheet metal with a maximum thickness of 2mm. It features rollers for straightening and a precision cutting mechanism for accurate material preparation.
Technical Specifications
Overview
High-Precision Straightening and Cutting Solution
This high-precision straightening and cutting machine is engineered for the efficient processing of sheet metal up to 2.0mm thick. It integrates advanced traction and leveling functions, utilizing a robust roller system with hard chromium plating for enhanced longevity. Equipped with a hydraulic power system and a PLC control unit, this machine ensures consistent, accurate performance for demanding industrial applications.
Technical Specifications
Main Power
5.5 kW
Power Rating
- Material Thickness Capacity
- 1.5 mm
- Operating Speed
- 10-15 m/min
- Electrical Requirements
- 415V/50HZ/3 Phase
Mechanical Construction
- Straightening Rollers Configuration
- 4+5 rollers
- Shaft Material
- #45 Steel (Heat Treated)
- Blade Material
- GCr12
Features
- Key Features
- PLC Control SystemHydraulic Motor DrivenHard Chromium Plated RollersManual DecoilerCylinder Lifting
- Included Decoiler Capacity
- 5 T
