Steel Coil Straightening and Cutting Machine
This straightening and cutting machine is designed for processing steel coils. It utilizes rollers to straighten the material and a cutting mechanism to produce sheets or blanks of desired lengths.
Technical Specifications
Product Overview
High-Precision Steel Coil Processing
This high-precision straightening and leveling machine is engineered for efficient steel coil processing. It integrates advanced traction and leveling capabilities through a robust roller system designed for long-term industrial service. Featuring an automated PLC control system and hydraulic operation, this machine ensures consistent accuracy and ease of use in cutting and straightening applications.
Technical Specifications
Processing Speed
15 m/min
Max Speed
- Working Material Thickness
- 1.5 mm
- Electrical Requirements
- 415V50HZ3 Phase
Mechanical Components
- Hydraulic Motor Power
- 5.5 KW
- Straightening Rollers
- 4
- Shaft Material
- #45 Heat Treated Steel
- Blade Material
- GCr12
Features
Control System
PLC IntegratedHydraulic LiftingHard Chromium Plated Rollers
- Decoiler Capacity
- 5 T
