Technical Specifications
Overview
High-Performance Motor Grader
This heavy-duty motor grader is engineered for precision grading, leveling, and earthmoving tasks in demanding construction environments. Featuring a powerful 220hp engine and an advanced hydraulic system, it ensures consistent power output and maneuverability across diverse terrains. With its versatile, fully adjustable blade and robust frame design, this machine is an essential tool for road construction, site preparation, and surface maintenance.
Performance Metrics
Key Performance Metrics
220 hp
Rated Power
16,500 kg
Overall Weight
4,256 mm
Blade Length
Overall Dimensions
Machine Dimensions
| Specification | Value |
|---|---|
| L×W×H | 8900×2700×3500mm |
| Wheelbase | 6840mm |
| Wheel tread | 1685mm |
| Rear axle wheelbase | 1650mm |
Engine & Powertrain
Engine Specifications
- Rated speed: 2400 rpm
- Certified capacity: 6.75L
- Min. fuel consumption rate: ≤230g/(kw.h)
Blade & Grading
Blade Capabilities
- Blade swing angle: 360°
- Cutting depth: 360mm
- Blade sliding range: 600mm (Left/Right)
- Blade inclination: Forward 47° / Backward 5°
Operational Parameters
- Steering & Maneuverability
- Front axle swing: ±16°Front wheel steering: ±45°Articulated frame steering: ±25°
Capacities
Fluid Capacities
220 L
Fuel Tank
140 L
Hydraulic Oil
