Refrigerated Cake Display Case
This refrigerated display case is designed for showcasing cakes and pastries. It features ultra-white heating glass and LED lighting for enhanced visibility and an optimal cooling temperature.
Technical Specifications
Product Overview
Professional Refrigerated Cake Display Case
This premium cake display case features ultra-white heating glass and high-brightness LED lighting to ensure an optimal visual presentation of your products. Engineered for performance, it reaches a steady 5°C temperature within 20 minutes of startup, even in high ambient temperatures of 30°C. With high-quality imported components like Embraco compressors and Dixell controllers, this unit maintains a clear, fog-free environment even while doors are open for service.
Key Features
Cooling Performance
5 °C
Target Temp
20 min
Cooling Speed
- Compliance and Standards
- CE CertifiedRoHS Compliant
Technical Specifications
Model Dimensions
| Model | Cabinet Size (mm) | Packing Size (mm) |
|---|---|---|
| QS730V-ME | 900x680x1200 | 1000x780x1300 |
| QS740V-ME | 1200x680x1200 | 1300x780x1300 |
| QS750V-ME | 1500x680x1200 | 1600x780x1300 |
| QS760V-ME | 1800x680x1200 | 1900x780x1300 |
| QS770V-ME | 2100x680x1200 | 2200x780x1300 |
| QS780V-ME | 2400x680x1200 | 2500x780x1300 |
Core Components
- Compressor: Embraco
- Controller: Dixell
- Gas: R134a
- Glass: ITO with heating film
Operational Details
- Interior Lighting
- LED-6500K
- Temperature Range
- +2°C to +8°C
- Access Type
- Sliding doors on back
