Technical Specifications
Product Overview
Versatile Polypropylene Camlock Couplings
These polypropylene cam and groove quick couplings are designed for high efficiency, eliminating the need for complex threaded or flanged operations. Constructed from lightweight, durable polypropylene, they offer excellent chemical and abrasion resistance suitable for industrial, agricultural, and commercial fluid transfer. The integrated safety lock mechanism ensures reliable operation by preventing accidental disconnections during use.
Technical Specifications
Available Sizes
- 1/2"
- 3/4"
- 1"
- 1 1/4"
- 1 1/2"
- 2"
- 2 1/2"
- 3"
- 4"
Working Pressure
100 psi
1" to 2 1/2"
50 psi
3" to 4"
- Temperature Range
- -30°F to 200°F
Construction & Materials
- Handle Materials
- BrassStainless Steel
- Gasket Materials
- NBREPDMVitonPTFE
- Safety Pin Materials
- Carbon steel platedStainless steel
Compatibility
Thread Standards
- ISO228 (BSP)
- ISO7 (BSPT)
- ANSI B1.20 (NPT)
Compatible Media
OilWaterGasChemicalsPetroleum
