Stainless Steel Camlock Quick Coupling Female Adapter
This quick coupling offers excellent corrosion resistance and performs well in high-temperature environments. Its durable construction ensures a long service life and broad working temperature range.
Technical Specifications
Overview
High-Performance Stainless Steel Camlock Couplings
These stainless steel camlock couplings are precision-engineered for rapid, secure connections in industrial fluid transfer systems. Designed for exceptional corrosion resistance and high-temperature tolerance, they are ideal for handling water, wastewater, chemicals, hydraulic oil, and coolants. Built to meet international standards, these fittings ensure long service life and reliable performance in demanding environments.
Technical Specifications
Available Sizes
- 1/2"
- 3/4"
- 1"
- 1-1/4"
- 1-1/2"
- 2"
- 2-1/2"
- 3"
- 4"
- 6"
- 8"
- Material Composition
- Stainless Steel 316Stainless Steel 304
- Thread Standards
- NPTBSPPBSPT
Performance Metrics
Working Pressure Ratings
250 PSI
3/4" to 2"
225 PSI
2-1/2"
200 PSI
3" to 4"
150 PSI
6"
- Temperature Range
- -150°F to +500°F
Construction & Standards
Workmanship
Precision CastingForged
Component Materials
| Component | Material Options |
|---|---|
| Pins, Rings, Safety Clip | Carbon steel plated, Stainless steel |
| Handle | Brass, Stainless steel |
| Seal | NBR, BUNA, EPDM, VITON |
- Standards Compliance
- A-A-59326MIL-C-27487DIN 2828
