Pinch Plate Press for Metal Forming
This pinch plate press is designed for shaping and forming metal sheets with accuracy and efficiency. Its robust construction ensures durability, while adjustable pressure settings allow for versatile material handling.
Technical Specifications
Product Overview
Precision Pinch Plate Roll Forming
This industrial-grade pinch plate roll forming machine is engineered for high-accuracy metal shaping and processing. Designed to handle galvanized steel and PPGI sheets with thickness ranging from 0.3mm to 0.8mm, it offers a robust solution for demanding production environments. With a 16-step forming process and a reliable hydraulic cutting system, it ensures consistent, high-quality output for industrial metalworking applications.
Material Capabilities
Processing Specifications
| Parameter | Value |
|---|---|
| Compatible Materials | Galvanized steel, PPGI |
| Material Thickness | 0.3 - 0.8 mm |
| Yield Strength | 235 - 450 MPa |
Machine Dimensions & Power
Key Performance Metrics
2.5 T
Machine Weight
10 m/min
Max Working Speed
5.5 kw
Motor Power
- Power Supply
- 380V, 50Hz, 3 Phase
Technical Construction
Construction Details
- 16 Forming Stations
- 45# Steel Rollers (Quenched and Chrome Plated)
- 45# Steel Shaft
- Cr12mov Cutter
- Chain Transportation System
Certifications
Quality Standards
CEISO 9001SGS
Service & Support
- Warranty & Service
- 1-year warranty with 24/7 online support and overseas engineer assistance available.
