Multifunction Battery Charger with Engine Start and Tester
This is a multi-functional device designed for automotive battery maintenance and diagnostics. It features a built-in tester for assessing battery health and charging performance, as well as an engine start function to deliver a high current boost to start vehicles with depleted batteries.
Technical Specifications
Overview
Professional Multifunction Battery Maintenance
This advanced microprocessor-controlled unit is designed for versatile battery maintenance, supporting both 6V and 12V systems. It combines charging, diagnostic testing, and engine starting capabilities into one compact, lightweight device. With high transfer efficiency and comprehensive safety protections, it is an essential tool for automotive workshops and vehicle maintenance.
Performance & Technical Specs
Charging Current Options
- 2
- 5
- 15
Performance Metrics
93 %
Transfer Efficiency
15 A
Continuous Output
45 A
Max Starting Current
- Supported Battery Types
- AGMGELWETSTDLFP (Lithium)
Features & Diagnostics
Diagnostic Functions
Battery Voltage TesterAlternator Tester13.6V StabilizerAdjustable Power Supply
Safety & Protection
Safety Protections
- Short circuit protection
- Reverse polarity protection
- Overload protection
- Overheat protection
