Multifunction Battery Charger with Engine Start and Tester
This is a multifunction battery charger with an engine start function and a built-in tester. It features multiple charging modes for various battery types, adjustable amperage settings, and a user-friendly interface.
Technical Specifications
Overview
Professional Multifunction Power Solution
This intelligent microprocessor-controlled unit serves as a comprehensive battery management system, combining charging, testing, and engine starting capabilities in one compact design. It supports a wide range of battery chemistries, including AGM, GEL, WET, STD, and LFP, ensuring versatility for various automotive applications. With an outstanding transfer efficiency of up to 93%, this device offers reliable performance for both maintenance and emergency power needs.
Technical Specifications
Selectable Charging Currents
- 2
- 5
- 10
- 20
- Supported Voltages
- 6V12V
- Compatible Battery Types
- AGMGELWETSTDLFP
- Transfer Efficiency
- 93 %
Performance Metrics
Performance Highlights
75 A
Max Starting Current
20 A
Continuous Output
13.6 V
Stabilizer Voltage
Features & Diagnostics
Integrated Functions
Battery Voltage TesterAlternator TesterAdjustable Power SupplyMicroprocessor Control
Safety & Design
Safety Protections
- Short circuit protection
- Reverse polarity protection
- Overload protection
- Overheat protection
