Motorized Screw Jack for Heavy Lifting
This motorized screw jack is designed for effortless lifting and precise control. Its robust construction ensures durability and reliability in heavy-duty applications.
Technical Specifications
Product Overview
Heavy-Duty Lifting Solution
This motorized screw jack is engineered for demanding heavy-lifting applications, offering a robust and reliable solution for industrial and agricultural environments. Designed for precision and ease of use, the unit features a durable forged steel construction capable of supporting substantial loads. The motorized mechanism enhances operational efficiency, reducing operator fatigue while ensuring stable and secure lifting performance.
Technical Specifications
Maximum Capacity
50 T
Rated Capacity
Operating Pressures
- Rated pressure: 31.2 Mpa
- Air pressure: 0.8-1.2 Mpa
Physical Dimensions
- Min Height: 200 mm
- Max Height: 320 mm
- Extension height: 40 mm / 75 mm
- Net Weight: 105 kg
Model Performance Data
| Model | Capacity (T) | Test Load (KN) | Lifting Dist (mm) |
|---|---|---|---|
| QJC-1.5A | 1.5 | 18.4 | 350 |
| QJC-3A | 3 | 36.8 | 350 |
| QJC-5A | 5 | 61.3 | 300 |
| QJC-10A | 10 | 122.5 | 300 |
| QJC-16A | 16 | 196 | 400 |
| QJC-20A | 20 | 245 | 400 |
Compliance & Logistics
- Certifications
- CE
- Lead Time
- 15 days after payment
