Technical Specifications
Overview
Modular Plastic Conveyor Belt HS-2500E
This modular plastic conveyor belt is engineered for high-performance food processing and industrial applications. Featuring a 25.4mm pitch and robust 13mm thickness, it offers reliable operation with a maximum load capacity of up to 1.2 tons per square meter. Designed for versatility, it is compatible with a wide range of materials and operating temperatures, ensuring consistent performance in demanding environments.
Technical Specifications
- Pitch
- 25.4 mm
- Belt Thickness
- 13 mm
- Minimum Width
- 50 mm
- Open Area
- 0 %
- Rod Diameter
- 4.9 mm
- Available Materials
- PPPOMPEPA
- Available Colors
- WhiteBlueGrayNaturalDark-brown
Capabilities
Working Temperature
-40 °C
Min Temp
260 °C
Max Temp
Certifications
FDA ApprovedEU Compliant
- Max Load Capacity
- 1.2 tons/square meter
Configuration
Sprocket Sizes
- 8T-2R
- 10T-2R
- 12T-2R
- 15T-2R
- 18T-2R
- 20T-2R
- 20T-2R-Split
Belt Features
| Feature | Status |
|---|---|
| Flight | No |
| Side Guard | No |
| Curve | No |
Applications
Suitable Industries
- Food Processing (Meat, Poultry, Seafood, Bakery, Snack Food, Fruit & Vegetables)
- Automotive
- Tire Manufacturing
- Packaging
- Printing/Paper
- Postal
- Corrugated Cardboard
- Can Manufacturing
- PET Manufacturing
- Textile
