Mobile Cone Crushing Plant
This mobile cone crushing plant utilizes a rotary cone crusher with a fully hydraulic closed side adjustment device. It is capable of producing 10-45mm aggregate, with adjustments made via a control box.
Technical Specifications
Product Overview
Mobile Cone Crushing Plant
The XRM-C series wheeled cone crushing plant is a highly mobile and efficient solution designed for secondary or tertiary crushing stages in mining, quarrying, and construction. Featuring a fully hydraulic closed side adjustment device, this plant allows for quick and convenient discharge port parameter changes directly via the control box. It is engineered to produce high-quality 10-45mm aggregates with integrated feeding, screening, and conveying systems for a continuous production process.
Key Features
- Key Features
- Hydraulic AdjustmentWheeled MobilityIntegrated SystemAutomated ControlHigh Crushing Ratio
Technical Specifications
Technical Parameter List
| Parameter | XRM-C120 | XRM-C180S | XRM-C180 | XRM-C250S | XRM-C250 |
|---|---|---|---|---|---|
| Length (mm) | 11200 | 11800 | 10000 | 12300 | 10816 |
| Width (mm) | 2743 | 2743 | 2480 | 2900 | 2743 |
| Height (mm) | 4200 | 4200 | 4160 | 4200 | 4160 |
| Weight (kg) | 28400 | 30500 | 22400 | 48700 | 35700 |
| Max Feed (mm) | 160 | 180 | 180 | 240 | 240 |
Component Details
Crusher Components
- Hydraulic Cone Crusher
- Vibrating Screen
- Belt Conveyor
- Wheeled Chassis
- Hydraulic Support Legs
- Control Cabin
