Millimeter Wave Radar Detection System with 1080P Camera
This 1080P 77GHz radar detection system uses millimeter-wave technology. Designed for heavy vehicles, it provides visual and audible alerts to operators, enabling proactive safety measures.
Technical Specifications
Product Overview
Advanced Safety Solution
This 77GHz millimeter-wave radar detection system is engineered for heavy vehicles, including trucks, construction, and agricultural machinery. By integrating high-definition 1080P camera technology with precise radar sensing, it provides operators with visual and audible alerts to mitigate blind spot dangers. Designed for all-weather reliability, the system ensures 24-hour operation, significantly enhancing safety during reversing, parking, and lane changes.
Technical Specifications
- Radar Frequency
- 77GHz
- Video Resolution
- 1080P
- Environmental Capability
- All-weather operation24-hour monitoringFog resistantRain resistant
System Components
Included Components
- 1080P Camera (FHD-639)
- Monitor (HD-261D)
- Radar Sensor
- Control Box
- Buzzer
System Features
Core Capabilities
AHD Image alarm overlappingDetection range limitWidth limitWi-Fi configuration support
Configuration Methods
- Computer (USB to UART)
- Mobile Phone (Optional)
Applications
- Suitable For
- Heavy TrucksConstruction MachineryAgricultural Machinery
