Metal Crushing Machine
The metal crushing machine is a popular piece of equipment used in the metal recycling industry. It efficiently crushes various materials such as Sprite tins, Lulu tins, Red Bull tins, Coke tins, paint tanks, and machine oil tanks for easy handling and delivery.
Technical Specifications
Overview
High-Efficiency Metal Processing
This industrial-grade metal crushing machine is designed for the metal recycling industry, capable of processing diverse materials including tin cans, paint tanks, and machine oil tanks. Engineered for durability, the unit features a high-alloy blade system for superior crushing performance on high-hardness materials. The machine utilizes a high-torque motor and gear-driven system to optimize energy consumption while maintaining consistent output capacity.
Performance Metrics
Key Performance Metrics
4.5 t/h
Max Processing Capacity
105 kw
Max Motor Power
1,800 r/min
Max Rotating Speed
Operational Features
Operational Advantages
- Gear motor drive saves up to 20% electricity
- Low-noise startup operation
- High-alloy blade for high-hardness materials
- Reinforced cabinet structure
- Compatible with conveyor and feeding systems
- Operating Systems
- Dry SystemWet SystemHalf Wet System
Technical Specifications
Model Specifications
| Model | Feeding Size (mm) | Capacity (t/h) | Power (kw) | Weight (t) |
|---|---|---|---|---|
| HJ-600 | 500×600 | 0.5-0.7 | 18.5 | 2.2 |
| HJ-800 | 700×800 | 1-1.2 | 30 | 3.6 |
| HJ-1000 | 900×1000 | 2.5-3 | 75 | 6.5 |
| HJ-1200 | 1000×1200 | 3-3.5 | 90 | 10 |
| HJ-1600 | 1200×1600 | 3.5-4.5 | 105 | 19 |
