Metal Blanking and Punching Press Line
The Metal Blanking and Punching Press Line is designed for high-volume shearing and punching operations. This automated system integrates material handling with precision pressing to ensure efficient production and consistent quality.
Technical Specifications
Product Overview
High-Efficiency Metal Blanking Line
The YB-L Series is a robust hydraulic press line designed for high-accuracy blanking and spinning forming of metal sheets. Engineered with an H-frame guidance structure, it ensures superior stiffness and precision during high-volume production. This automated system integrates seamless connectivity with auxiliary machinery to minimize raw material waste and maximize operational throughput.
Technical Specifications
- Frame Design
- H-frame guidance structure
- Control Method
- PLC with touch screen interface
- Supported Sheet Widths
- 550mm1010mm1500mm
Key Features
Automation Components
- Automatic decoiling and straightening
- Material pressing and positioning mechanisms
- Discharge transmission system
- Programmable blanket moving length
Performance Metrics
Operational Highlights
100 %
Material Utilization Improvement
