Technical Specifications
Product Overview
JIS Marine Globe Valve
This Marine Globe Valve is manufactured in accordance with JIS F7311 and F7319 standards, making it a reliable solution for fluid control systems in marine environments. Constructed from high-quality cast steel, the valve is engineered for durability, precise sealing, and long-term operational efficiency. Its robust design ensures performance in demanding onboard applications, providing a safe and effective shutoff mechanism.
Standards & Compliance
- JIS Standards
- JIS F7311JIS F7319
Materials of Construction
Component Materials
| Component | Material |
|---|---|
| Body | SC450 |
| Bonnet | SC450 |
| Disc | BC6 / SCS2 |
| Valve Seat | BC6 / SCS2 |
| Stem | C3771BD / BE / SUS403 |
| Packing Gland | BC6 |
| Handwheel | FC200 |
| Gasket | Non-Asbestos |
Primary Material
Cast Steel
