LDPE Co-Extrusion Film Blowing Machine for Greenhouse Film
This co-extrusion film blowing machine is designed for producing LDPE greenhouse film. It creates film with a width range of 3 to 24 meters and a thickness of 0.05 to 0.2mm.
Technical Specifications
Overview
High-Performance Greenhouse Film Production
This advanced co-extrusion film blowing line is engineered for the high-volume production of agricultural greenhouse films. Supporting 1 to 5-layer co-extrusion, it allows for the precise integration of functional additives such as anti-UV, anti-fogging, and anti-dripping agents. The system is built for durability and precision, featuring robust components like an IBC inner cooling system and dual traction devices to ensure consistent film thickness and superior mechanical strength.
Technical Specifications
Film Capabilities
24 m
Max Unfolding Width
0.2 mm
Max Thickness
5 layers
Max Layers
Included Components
- Single-screw Extruder
- Screen Changer
- Die Head
- Air Ring (with cooling fan)
- Herringbone & Sizing Cage
- Dual Traction Devices
- Rewinder Device
- IBC Inner Cooling System
- Compatible Materials
- PELDPELLDPEmPEEVAMaster BatchRecycled Materials
Model Data
Model Comparison Table
| Model | Max Width (mm) | Die Diameter (mm) |
|---|---|---|
| 3FM3200 | 6,000 | 1,000 |
| 3FM2800 | 8,000 | 1,100 |
| 3FM3000 | 10,000 | 1,450 |
| 3FM3500 | 12,000 | 1,600 |
| 3FM4500 | 14,000 | 1,900 |
| 3FM5000 | 16,000 | 2,300 |
