Laser Welded Plate Heat Exchanger Machine
This laser welding machine is designed for manufacturing plate heat exchangers. It integrates a high-power laser, water-cooling unit, and numerical control system for precise and efficient welding.
Technical Specifications
Overview
High-Precision Laser Welding System
The GS-HHR10015-3500 is an advanced laser welding machine engineered for the precise assembly of plate heat exchangers. It integrates a high-power laser, numerical control system, and multi-stage conveying platform to ensure stable, reliable, and durable operation. Designed with operator safety in mind, the system features centralized parameter control and strong anti-interference capabilities for demanding industrial environments.
System Components
Core Components
- High-power Rofin-DC035 laser
- Water-cooling unit
- Welding host
- Numerical control system
- External light path system
- Two-end clamping mechanism
- Two-stage conveying platform
- Pressure feeding device
- Protective gas unit
Technical Specifications
- Laser Model
- Rofin-DC035
- Welding Machine Type
- GS-HHR10015
- Water Cooling Unit
- LSJR-600BX
- Optical Path
- Φ60
- Focusing System
- F=250
Air Compressor System
- Compressor Type
- Oil-free screw air compressor
- Model
- EAS-05JT / 8
- Discharge Pressure
- 0.8 Mpa
- Displacement
- 0.6 m³/min
- Motor Power
- 4 KW
- Reservoir Capacity
- 80 L
- Gross Weight
- 200 KG
- Dimensions
- 1050mm x 550mm x 1160mm
