Large Span Structural Profile Roll Forming Machine
This large span roll forming machine is designed for efficient manufacturing of structural components used in rail transit and construction. It handles heavy-duty materials, producing consistent, high-quality profiles with precision forming rollers.
Technical Specifications
Overview
Large Span Structural Solutions
This large span structural profile roll forming machine is engineered to replace traditional frame architecture with efficient, arched metal structures. By transforming PPGI material into precise arch grooves, the system enables rapid construction of durable, long-span buildings. It is an ideal solution for projects requiring wide spans, low construction costs, and long service life.
Technical Specifications
- Model Number
- ZX-700
- Board Width
- 914 mm
- Effective Width
- 700 mm
- Material Usage Rate
- 76.6 %
Performance
Proper Span Range
7 m
Minimum Span
24 m
Maximum Span
Key Features
Operational Advantages
- Fast construction speed
- Low cost implementation
- Long service life
- Large span capability
- Aesthetically pleasing shape
