Industrial Color Coating Line for Metal and Film
This industrial color coating line is engineered for applying coatings to metal sheets and films such as PET, PVC and aluminum. It features vector control for high-precision drive, simplified maintenance, and ease of control.
Technical Specifications
Product Overview
Industrial Color Coating Line
This industrial color coating line is designed for the continuous application of organic paint layers onto metal substrates, including cold-rolled, galvanized, and galvalume plates. Engineered for high-volume output, it ensures uniform quality and efficiency for applications in both home appliances and construction sectors. The system incorporates advanced features like vector control for high-precision operation and waste heat recovery for improved energy efficiency.
Substrate Specifications
Dimensions
0.2 mm
Min Thickness
1.2 mm
Max Thickness
600 mm
Min Width
1,250 mm
Max Width
Mechanical Properties
| Property | CR Plate | GI/GL Plate |
|---|---|---|
| Yield Strength | 130~350 MPa | 130~380 MPa |
| Tensile Strength | 250~420 MPa | 250~420 MPa |
- Compatible Materials
- Cold Rolling Plate (CR)Galvanizing Plate (GI)Galvalume Plate (GL)Stainless Steel
Line Performance
Operational Capacity
150 m/min
Max Line Speed
150,000 tons/year
Max Annual Output
Coating Details
- Continuous two-coating two-braking on each side
- Positive side dry film: 5~15μm
- Back side primer paint: 5~10μm
Technical Features
System Features
- Vector control drive for high-precision and easy maintenance
- Two-grade chemical degreasing
- Three-grade water rinsing and spraying
- Waste gas incineration and heat recovery system
- Energy & Fuel Sources
- CNGElectricityLPGCoalCoal Gas
