Hydraulic Rock Breaker for Excavators
This hydraulic breaker utilizes pressure oil from an excavator or loader pump station. It is used with power excavators for tasks such as mining hard objects, reinforced concrete, and old buildings.
Technical Specifications
Overview
High-Performance Hydraulic Rock Breaker
This hydraulic rock breaker is engineered for demanding demolition and construction environments, providing high impact energy for efficient rock excavation and concrete breaking. Designed with robust components to ensure durability and minimal maintenance, it offers professional-grade reliability on the job site. The unit is versatile, featuring broad compatibility with various major excavator models in the 2.5 to 4.5-ton range.
Technical Specifications
Weight Specifications
89 kg
Body Weight (incl. chisel)
158 kg
Total Weight
Operating Parameters
25 l/min
Hydraulic Oil Flow Min
50 l/min
Hydraulic Oil Flow Max
90 Kg/cm2
Pressure Min
120 Kg/cm2
Pressure Max
- Dimensions (L x W x H)
- 1178 x 230 x 500 mm
- Performance
- 600–1100 bpm blow frequency
- Chisel Diameter
- 53 mm
Compatibility
Compatible Carrier Brands/Models
- XCMG 40
- CAT 303C CR / 303.5C CR
- KOMATSU PC10/12/15/20/27
- HYUNDAI ROBEX35
- DOOSAN DAEWOO DH30/DSL602/SOLAR30/035
- HITACHI EX25/27/30/33/34/UE30
- KOBELCO SK035
- VOLVO EC30/25/35
- KUBOTA 35
- SUNWARD SWE30/40
Commercial Terms
Logistics & Payment
| Term | Details |
|---|---|
| MOQ | 1 Unit |
| Payment Methods | T/T, Western Union, Paypal, L/C |
| Delivery Time | 7 days after advance payment |
| Shipping Ports | Yantai, Qingdao, Shanghai, Tianjin, Guangdong |
- Quality Standards
- CE
