Hydraulic Pipe and Tube Clamps
These hydraulic clamps are designed for securing pipes and tubes in hydraulic systems. Constructed from aluminum and plastic, the clamps offer durability, corrosion resistance, and reliable support.
Technical Specifications
Overview
Versatile Hydraulic Pipe & Tube Clamps
These hydraulic pipe and tube clamps provide a robust and reliable solution for securing hydraulic systems, offering excellent vibration dampening and stability. Designed with a split-body structure for easy installation and maintenance, they are suitable for a wide range of industrial applications. The clamps are constructed from high-quality materials like aluminium and polypropylene to ensure long-term performance and corrosion resistance in demanding environments.
Technical Specifications
Outer Diameter Range
6 mm
Min O.D.
805 mm
Max O.D.
Working Temperature Range
| Material | Min Temp | Max Temp | Typical Color |
|---|---|---|---|
| Polypropylene (PP) | -30°C | +90°C | Dark Green |
| Polyamide (PA) | -40°C | +120°C | Dark |
Material & Construction
Assembly Components
- Cover Plate
- Weld Plate
- Clamp Body
- Hexagon Bolts
Hardware Materials
- Carbon Steel (Zinc Coated)
- Carbon Steel (Phosphated)
- Stainless Steel
- Clamp Body Materials
- Polypropylene (PP)Polyamide (PA)Aluminium (AL)
Performance Features
Key Benefits
Vibration DampeningCorrosion ResistantHigh Pressure SupportEasy Installation
