Hydraulic Mooring Winch
This electric mooring winch has a rated pull of 20KN and a speed of ≥12 m/min. It is designed with a drum capacity of Φ15*100m.
Technical Specifications
Overview
Professional Hydraulic Mooring Winch
This hydraulic mooring winch is engineered for demanding marine environments, offering robust performance for anchoring and mooring operations. Designed with a high-capacity gear system and hydraulic drive, it ensures precise control and reliability on ships, docks, and offshore platforms. The equipment is built to meet international standards, ensuring safety and durability under significant load conditions.
Certifications
- Authorized Certifications
- CCSLRGLRS
Technical Specifications
Model Specifications
| Model | Load (kN) | Power (kW) | Speed (m/min) |
|---|---|---|---|
| DY30 | 30 | 18.5 | 15 |
| DY40 | 40 | 18.5 | 15 |
| DY50 | 50 | 15 | 15 |
| DY60 | 60 | 30 | 15 |
| DY70 | 70 | 30 | 15 |
| DY80 | 80 | 45 | 15 |
| DY125 | 125 | 55 | 15 |
| DY160 | 160 | 75 | 15 |
| DY200 | 200 | 90 | 15 |
| DY250 | 250 | 110 | 15 |
- Chain Diameter Range
- 12.5 mm to 60 mm
