Technical Specifications
Overview
High-Efficiency Hydraulic Jaw Crusher
This European-style hydraulic jaw crusher is engineered for primary crushing of medium to hard ores, rocks, and slag with compressive strengths up to 280MPa. It features a robust, integral cast steel bearing seat and a V-shaped crushing cavity designed to prevent material blockage and maximize throughput. Equipped with advanced hydraulic systems for both lubrication and cavity cleaning, this machine ensures reliable operation and significantly reduced downtime for industrial applications.
- Suitable Industries
- MiningMetallurgyChemical IndustryCement ProductionConstructionRefractory MaterialsCeramics
Technical Specifications
Technical Parameters
| Model | Inlet Size (mm) | Max Feed (mm) | Output (t/h) | Power (kW) | Weight (kg) |
|---|---|---|---|---|---|
| PEY860 | 860x1100 | ≤720 | 200-500 | 132-160 | 32,000 |
| PEY1100 | 1100x1200 | ≤930 | 300-650 | 185-200 | 59,200 |
| PEY200x1300 | 200x1300 | ≤180 | 12-35 | 30-37 | 7,500 |
| PEY250x1000 | 250x1000 | ≤220 | 15-50 | 30-37 | 6,800 |
| PEY250x1200 | 250x1200 | ≤220 | 20-50 | 37-45 | 7,800 |
Key Features
Design Advantages
- V-shape crushing cavity and toothed guard design for consistent feeding
- Hydraulic oil station for automated lubrication and safety monitoring
- Hydraulic cavity cleaning system for rapid blockage clearance
- Gasket-type discharge opening adjustment for flexible output control
- Integral cast steel bearing seat for enhanced structural stability
