Hydraulic Crimping Head
This hydraulic crimping head delivers a crimping force of 350kN. It is designed for crimping operations on connectors and terminals within a range of 300mm2-1000mm2.
Technical Specifications
Product Overview
Professional Grade Hydraulic Crimping
The T-1000 is a high-performance hydraulic crimping head engineered for heavy-duty electrical infrastructure projects. It provides a significant 350kN crimping force, ensuring reliable and consistent connections for large cross-section conductors. Compatible with a variety of external hydraulic pumps, this tool is ideal for substation maintenance and overhead line construction.
Technical Specifications
Crimping Force
350 kN
Crimping Force
- Weight
- 12 kg
Performance Data
Crimping Capacity
| Conductor Material | Range (mm²) | Die Series |
|---|---|---|
| Copper | 500-1000 | MT |
| Aluminium | 300-1000 | ML |
Package Information
Included Components
- T-1000 Hydraulic Crimping Head
- Die set
- Manual
- Spare seal ring
- Plastic carry case
