Hydraulic Anchor Windlass for Marine Vessels
This winch is designed for vertically lifting anchors or heavy equipment on boats. It can be driven by an electric motor, hydraulic pump system, or diesel engine.
Technical Specifications
Product Overview
Robust Marine Anchor Handling
This heavy-duty hydraulic anchor windlass is engineered for reliable performance in demanding marine environments. Designed for efficient anchor deployment and mooring operations, it features a powerful hydraulic drive system and durable construction to withstand harsh conditions. Available in multiple configurations to suit various vessel sizes, it ensures precision and safety for critical maritime tasks.
- Key Features
- Hydraulic DriveHeavy-Duty ConstructionAnchor HandlingMooring OperationsCorrosion Resistant
Technical Specifications
Performance Data by Model
| Model | Chain Dia (mm) | Working Load (KN) | Supporting Load (KN) | Motor Power (KW) | Weight (T) |
|---|---|---|---|---|---|
| CM-24 | 24 | 25-27 | 149-214 | 8.5/3.5 | 3.3 |
| CM-26 | 26 | 29-32 | 175-250 | 8.5/3.5 | 3.3 |
| CM-28 | 28 | 33-37 | 202-289 | 11/11/7.5 | 3.8 |
| CM-30 | 30 | 38-42 | 231-331 | 11/11/7.5 | 3.8 |
| CM-32 | 32 | 44-49 | 262-375 | 16/16/11 | 4.6 |
| CM-34 | 34 | 49-55 | 295-422 | 16/16/11 | 4.6 |
| CM-36 | 36 | 55-62 | 329-473 | 16/16/11 | 4.6 |
| CM-38 | 38 | 61-69 | 365-522 | 22/22/16 | 5.2 |
| CM-40 | 40 | 68-76 | 403-576 | 22/22/16 | 5.2 |
| CM-42 | 42 | 75-84 | 442-630 | 22/22/16 | 5.2 |
Standard Operating Speeds
9 m/min
Working Speed
8.5 m/min
Warping Speed
