Highway Guardrail Roll Forming Machine for W-Beams and Crash Barriers
This roll forming machine is engineered for the efficient production of highway guardrails, W-beams, and crash barriers. Its automated operation and adjustable parameters ensure high-quality output and flexibility for various production needs.
Technical Specifications
Overview
High-Efficiency Guardrail Production
This highway guardrail roll forming machine is engineered for the high-volume production of W-beam crash barriers. It features a comprehensive, automated system including decoiling, leveling, punching, and precision roll forming to ensure consistent quality. Designed for durability and industrial performance, it utilizes advanced PLC controls to streamline operations and optimize material usage for infrastructure projects.
Technical Specifications
Performance Metrics
22 kw
Main Motor Power
11 kw
Hydraulic Station Power
12 m/min
Max Forming Speed
20 mpa
Hydraulic Pressure
Material Capabilities
| Parameter | Specification |
|---|---|
| Feed Width | 480mm |
| Forming Thickness | 2.0 - 3.2mm |
| Material Type | Q235 galvanized steel strip |
Construction Details
- 17 Roll forming stations
- GCr15 bearing steel rollers with quenched treatment
- Cr12 mould steel cutter blades with quenched treatment
- Total weight: Approx. 25 Ton
System Components
- System Components
- DecoilerLevelling SystemPunching SystemCoil Feeding MachineGuiderRoll Forming MachineCutting SystemCollecting PlatformPLC Controlling System
