Heavy-Duty Hammer Crusher
This heavy hammer crusher is suitable for crushing various raw materials in industries such as highways, railways, and building materials. The machine features a large feeding size and small discharging size.
Technical Specifications
Product Overview
Heavy-Duty Hammer Crusher
The Heavy-Duty Hammer Crusher is a versatile and efficient solution designed for crushing a wide range of raw materials in demanding industries such as mining, metallurgy, chemical processing, and infrastructure construction. Utilizing a high-speed rotating rotor equipped with heavy hammers, the machine effectively reduces material size through impact, shear, and grinding. Its robust construction ensures durability, while the adjustable discharge system allows for precise control over output particle size, making it suitable for both primary and secondary crushing stages.
Key Features
Advantages
- Large feeding size capacity
- High crushing ratio and efficiency
- Simple, compact, and lightweight structure
- Produces uniform particle size
- Easy maintenance with low wear and tear
- Energy-efficient operation
Technical Data
Detailed Specifications
| Model | Rotor (mm) | Feed Opening (mm) | Max Feed (mm) | Capacity (t/h) | Power (kW) | Weight (t) |
|---|---|---|---|---|---|---|
| PCZ1310 | 1300×1000 | 1020×750 | 600 | 100-180 | 132 | 16.2 |
| PCZ1510 | 1500×1000 | 1530×850 | 700 | 200-250 | 110×2 | 24.3 |
| PCZ1515 | 1500×1500 | 1530×900 | 750 | 260-350 | 132×2 | 30.1 |
| PCZ1616 | 1600×1600 | 1640×1200 | 1,000 | 500-600 | 220×2 | 39.8 |
| PCZ1818 | 1800×1800 | 1850×1400 | 1,200 | 650-800 | 280×2 | 63.6 |
Operational Metrics
Performance Range
Applications
- Suitable Industries
- MiningHighwaysRailwaysTunnelsCementMetallurgyChemical IndustryCoal
