Hammer Crusher
The hammer crusher efficiently reduces materials with a maximum particle size of 600-1800 mm to 25 mm or less. Suitable for crushing medium-hard materials like limestone, coke, and coal, it is used in cement, chemical, power, and metallurgy industries.
Technical Specifications
Product Overview
Hammer Crusher Efficiency
The Hammer Crusher is a robust solution engineered for the efficient reduction of medium-hard and brittle materials such as limestone, cinder, coke, and coal. It is capable of handling large input sizes and crushing them down to a uniform, fine output in a single stage, making it ideal for the cement, chemical, electric power, and metallurgy industries. Designed for continuous operation, the system features a high-speed rotor and wear-resistant components to ensure high productivity and minimal downtime.
Key Features
- Key Features
- High Crushing RatioUniform Particle SizeWear-Resistant LiningAdjustable Discharge SizeEasy Maintenance
Technical Specifications
Model Specifications
| Model | Feed Size (mm) | Production (m³/h) | Motor Power (kW) | Weight (t) |
|---|---|---|---|---|
| PCF400×300 | ≤200 | 5-10 | 11 | 0.8 |
| PCF600×400 | ≤250 | 10-22 | 22 | 2.26 |
| PCF800×600 | <250 | 18-40 | 55 | 4.8 |
| PCF1000×800 | ≤350 | 25-50 | 75 | 5.9 |
| PCF1000×1000 | ≤350 | 30-55 | 90 | 8 |
| PCF1250×1250 | ≤350 | 35-65 | 132 | 14 |
| PCF1400×1400 | ≤350 | 50-100 | 280 | 32 |
| PCF1600×1600 | ≤350 | 100-150 | 480 | 37.5 |
Application
Target Industries
- Cement Manufacturing
- Chemical Processing
- Electric Power Generation
- Metallurgy
- Mining
- Construction Materials
