GT60 Threaded Tungsten Carbide Button Bit
GT60 threaded button bits are designed for drilling in diverse rock formations and site conditions. These bits offer extended service life and achieve higher penetration rates.
Technical Specifications
Product Overview
High-Performance Drilling Solutions
These GT60 thread button bits are engineered for demanding benching and production drilling applications. Designed to adapt to a wide range of rock formations and site conditions, they offer superior penetration rates and extended service life. Built with high-grade alloy steel and durable tungsten carbide tips, these bits ensure reliable energy transfer and consistent performance in the field.
Technical Specifications
Body Configuration
Normal bodyRetrac body
Diameter Range
32 mm
Min Diameter
127 mm
Max Diameter
Available Thread Types
- R22
- R25
- R28
- R32
- R38
- T38
- T45
- T51
- ST58
- ST68
- GT60
Design Options
| Feature | Available Types |
|---|---|
| Button Shape | Spherical, Ballistic |
| Face Shape | Flat, Drop-center |
- Materials
- Alloy steel bar 45CrNiMoVTungsten carbide tips YK05
