GT60 Rock Drilling Button Bit
These GT60 thread button bits are suitable for various rock formations and drilling site conditions. They offer longer life and higher penetration rates.
Technical Specifications
Product Overview
High-Performance Rock Drilling Solutions
These GT60 rock drilling button bits are engineered for superior performance in mining, tunneling, and construction applications. Constructed from high-grade alloy steel and durable tungsten carbide tips, they ensure optimal rock penetration rates and extended service life. Designed to withstand demanding drilling conditions, these bits provide efficient energy transfer and reliable performance across various rock formations.
Technical Specifications
- Material
- 45CrNiMoV Alloy SteelYK05 Tungsten Carbide
- Body Type
- Normal or Retrac
- Button Shape
- SphericalBallistic
- Face Shape
- FlatDrop-center
- Diameter Range
- 127 mm
Compatibility
Supported Thread Types
- R22
- R25
- R28
- R32
- R38
- T38
- T45
- T51
- ST58
- ST68
- GT60
Available Size Configurations
| Thread Type | Available Diameters (mm) |
|---|---|
| R22 | 32, 36, 38, 41 |
| R25 | 33, 35, 37, 38, 41, 43, 45 |
| R28 | 37, 38, 41, 43, 45, 48 |
| R32 | 41, 43, 45, 48, 51, 54, 57, 64, 76 |
| T38 | 64, 70, 76, 89, 102, 127 |
| T45 | 76, 89, 102 |
| T51 | 89, 102, 115, 127 |
| T60 | 92, 96, 102, 115, 118, 127, 140, 152 |
