Gasoline Rock Drill
The gasoline rock drill integrates drilling, splitting, tamping, and demolition functions. It is adaptable to sites without power or air pressure equipment, especially suitable for temporary projects in mines, railway, highway construction, and other fields.
Technical Specifications
Product Overview
High-Efficiency Portable Drilling
This gasoline-powered rock drill is an all-in-one professional tool designed for high-performance drilling, splitting, breaking, and tamping. Ideal for remote mining, road construction, and quarrying, it operates independently of external power or compressed air systems. The machine features an intuitive internal combustion engine design that allows for effortless operation and rapid setup in challenging field environments.
Key Performance Metrics
Core Performance
250 mm/min
Drilling Speed
6 m
Max Drilling Depth
200 r/min
Drill Rod Speed
Technical Specifications
Dimensions and Weight
| Metric | Value |
|---|---|
| Weight | 27 kg |
| Dimensions | 746 x 315 x 229 mm |
Engine System
- Type: Single cylinder, air-cooled, two-stroke
- Displacement: 185 cm3
- Engine Speed: ≥2450 r/min
- Carburetor: Hand needle valve, no floating type
- Ignition: Controllable silicon contactless system
Fuel & Maintenance
- Fuel Consumption: 0.122 L/m
- Tank Capacity: ≥ 1.14 L
- Mixing Ratio (Gasoline:Oil): 12:1
- Spark Plug Clearance: 0.5-0.7 mm
Applications
- Primary Applications
- MiningRoad ConstructionQuarryingNational Defense ConstructionGeological ExplorationConcrete Demolition
