Technical Specifications
Overview
Reliable Power Generation
This gasoline generator set is engineered for robust performance and versatile power output. Featuring a 4-stroke, forced-cooled engine, it provides a dependable energy source suitable for various professional and industrial applications. With dual voltage capabilities and an electric starting system, this unit is designed to meet demanding power requirements efficiently.
Engine & Performance
- Engine Model
- KP460
- Engine Type
- 4-stroke, forced-cooled, single-cylinder
- Displacement
- 460 ml
- Ignition System
- Non-contact transistorized magneto (TCI)
- Starting System
- ManualElectric
Power Output
Power Performance
8 KVA
Rated Power (220V)
9 KVA
Rated Power (380V)
8.5 KVA
Max Power (220V)
9.5 KVA
Max Power (380V)
- Rated Voltage
- 220/380
- Rated Frequency
- 50 Hz
Operational Specs
- Fuel Tank Capacity
- 30 L
- Fuel Consumption
- 3.2 L/hr
- Continuous Operating Hours
- 9 hr
- Engine Oil Capacity
- 1.1 L
- Noise Level (at 7m)
- 80 dB
Logistics
Container Loading Capacity
| Container Type | Quantity |
|---|---|
| 20GP | 122 |
| 40GP | 254 |
| 40HQ | 254 |
Dimensions & Weight
- Carton Dimensions: 730 x 565 x 590 mm
- Net Weight: 87/90 kg
