FDM 3D Printer with Heated Bed
This FDM 3D printer utilizes fused deposition modeling technology. It has a build volume of 220 x 220 x 300 mm and supports materials like PLA, ABS and TPU.
Technical Specifications
Overview
Professional FDM 3D Printer
This high-precision FDM 3D printer features a robust sheet metal CNC frame and a triple-axis cross structure for exceptional stability and quiet operation. Designed for reliability, it includes advanced features like power loss recovery, intelligent support generation, and an auto-adjusting filament feeder to handle both rigid and soft materials seamlessly. With a generous 220x220x300mm build volume and intuitive touchscreen controls, it is an ideal solution for prototyping and small-scale production.
Printing Performance
Precision Metrics
0.013 mm
XY Axis Precision
0.003 mm
Z Axis Precision
- Build Volume
- 220 x 220 x 300 mm
- Layer Thickness
- 0.05mm - 0.3mm
- Printing Speed
- 40mm/s - 60mm/s
Hardware & Build
Nozzle Specifications
| Feature | Value |
|---|---|
| Structure | Single Head |
| Diameter | 0.4mm |
| Max Temperature | 260°C |
Dimensions & Weight
- Machine Size: 390 x 390 x 550 mm
- Packaging Size: 520 x 520 x 680 mm
- Weight: 23 kg
- Frame Material
- Sheet Metal
Compatibility
- Supported Materials
- PLAABSTPU
- File Formats
- STLGcodedaeamfbmpjpg
- Software & OS
- Cura, PrintRun (Windows, Linux, Mac)
Features
Key Features
Power Loss RecoveryIntelligent SupportAuto-Adjusting FeederTouchscreen InterfaceProgress Preview
Electrical
- Power Requirements
- 100-220V, 50/60Hz, 300W
