Double Convex Lens
This double convex lens is engineered for optimal light convergence and image formation. It is ideal for use in optical instruments such as microscopes and telescopes.
Technical Specifications
Product Overview
Precision Double Convex Lens
These precision-engineered double convex lenses are designed for optimal light convergence and image formation. Manufactured from high-quality optical grade glass or Fused Silica, they ensure minimal distortion and maximum light transmission. They are ideal for integration into microscopes, telescopes, and various other optical instruments requiring sharp, high-resolution imaging.
Optical Specifications
Clear Aperture
85 %
Clear Aperture
- Material
- Optical GlassFused Silica
- Paraxial Focal Length Tolerance
- 2 %
- Surface Figure
- lambda/4 @632.8nm
- Surface Quality
- 60-40 S/D
Mechanical Tolerances
Diameter Tolerance
| Grade | Tolerance (mm) |
|---|---|
| Standard | +0.0, -0.15 |
| Precision | +0.0, -0.02 |
- Centration
- 3 arc minutes
- Bevel
- 0.25x45deg
