Diesel Engine for Power Generation
This diesel engine is designed for power generation. It features a direct injection combustion chamber for easy starting and low fuel consumption.
Technical Specifications
Product Overview
High-Performance Diesel Engine for Power Generation
This QC380D diesel engine is a robust, vertical in-line power solution specifically engineered for generator sets. Featuring a four-stroke, water-cooled design with direct injection, it delivers reliable performance for industrial and agricultural applications. Its naturally aspirated intake and wet cylinder liner construction ensure durability and ease of maintenance for long-term heavy-duty operation.
Core Performance
Performance Ratings
10 kW
Rated Output (1500 RPM)
12 kW
Rated Output (1800 RPM)
255 g/kw.h
Max Fuel Consumption
Engine Configuration
Engine Architecture
- Vertical orientation
- In-line cylinder arrangement
- Water-cooled cooling system
- Four-stroke cycle
- Naturally aspirated intake
Technical Specifications
Mechanical Details
| Feature | Specification |
|---|---|
| Cylinder Count | 3 |
| Bore & Stroke | 80mm x 90mm |
| Displacement | 1.357 L |
| Cylinder Liner | Wet type |
| Chamber Type | Direct injection |
| Flywheel Ring Gear Teeth | 115 |
Interface & Installation
Interface Standards
| Component | Standard/Size |
|---|---|
| Flywheel Cover | SAE 4# |
| Flywheel Type | SAE 7.5# |
| Fan Diameter | 410 mm |
| Smooth Speed Rate | ≤ 5% |
Application Features
- Key Features
- Power GenerationIndustrial GradeMechanical InjectionEasy MaintenanceCompact Design
