Diesel Engine for Generator Sets
This diesel engine is designed for generator sets. It is a four-cylinder, water-cooled engine with a direct injection system.
Technical Specifications
Overview
High-Performance Diesel Engine for Generator Sets
This remanufactured diesel engine is specifically engineered for reliable power generation, offering a versatile solution for 3-cylinder and 4-cylinder generator sets. With a power range of 45 HP to 55 HP, it features a vertical, in-line, four-stroke design with natural aspiration and water cooling for stable operation. Designed for durability and efficiency, it is an ideal choice for B2B buyers seeking robust industrial power components.
Key Performance Metrics
Performance Highlights
39.6 kW
Max Standby Output
3.857 L
Displacement
1,800 RPM
Rated Speed
Technical Specifications
Engine Type
- Vertical
- In-line
- Four-stroke
- Water-cooled
- Naturally aspirated
- Model
- QC4102D
- Cylinders & Bore
- 4 Cylinders, 102mm Bore x 118mm Stroke
- Compression Ratio
- 17
- Fuel Consumption Rate
- 230 g/kw-h
Operation & Maintenance
Starting Method
Electric
- Lubrication Method
- Combination of pressure and splash
- Combustion Chamber
- Direct injection
- Firing Order
- 1-3-4-2
Mechanical Interface
- Direction of Rotation
- Counterclockwise (viewed from flywheel side)
- Flywheel Cover Type
- SAE 3#
- Cylinder Liner Type
- Dry
Dimensions
Installation Dimensions
| Dimension Type | Value |
|---|---|
| Overall Length | 722 mm |
| Engine Height | 422 mm |
| Oil Pan Width | 290 mm |
| Flywheel Outer Diameter | 428.62 mm |
