DC Inverter Air Source Heat Pump with Integrated Water Tank
This air source heat pump features a DC inverter and a built-in water tank for energy-efficient heating and cooling. It uses a variable-speed compressor to adjust output based on demand.
Technical Specifications
Overview
High-Efficiency DC Inverter Heat Pump
This advanced air source heat pump system features integrated water storage, designed to provide efficient heating and cooling for residential and light commercial environments. By utilizing DC inverter technology, the compressor frequency automatically adjusts to current thermal demands, resulting in significant energy savings compared to traditional ON/OFF models. The system is built with high-quality components for durability, quiet operation, and reliable performance in various climates.
Key Features
- System Highlights
- DC Inverter TechnologyIntegrated Water TankWi-Fi EnabledAnti-Corrosive CoatingHigh COP EfficiencyLow Noise Operation
Technical Specifications
Performance Metrics
4.34
Max COP (Heating)
60 °C
Max Flow Temperature
200 L
Water Tank Capacity
Model Specifications
| Model | Heating Capacity (kW) | Cooling Capacity (kW) | COP |
|---|---|---|---|
| EV-DCA7 | 7.35 | 5.5 | 4.34 |
| EV-DCA9 | 9.3 | 7 | 4.32 |
| EV-DCA12 | 12.2 | 9.2 | 4.28 |
| EV-DCA16 | 16.1 | 12 | 4.23 |
- Electrical Requirements
- 380V / 3Ph / 50Hz
- Refrigerant
- R410A
Dimensions & Weight
- Indoor Unit Dimensions (WxDxH)
- 620 x 760 x 1810 mm
- Outdoor Unit Dimensions (WxDxH)
- 907-915 x 430 x 845-1245 mm
Operating Noise
Noise Levels
- Indoor: ≤48-49 dB(A)
- Outdoor: ≤45-49 dB(A)
