Convex Head Waterproof Elevator Pushbutton Switch
This is a convex head elevator pushbutton switch with a waterproof design. The XDL21-CL51 model is suitable for use in elevators and other environments where moisture is a concern.
Technical Specifications
Product Overview
Industrial Convex Head Elevator Pushbutton
The XDL21-CL51 is a professional-grade, waterproof convex head pushbutton switch engineered for demanding industrial environments. Designed for reliability in elevator control panels and distribution systems, this switch offers robust mechanical durability with an IP65 protection rating. It is built with high-grade anti-flame plastics and silver alloy contacts to ensure superior electrical erosion resistance and consistent performance under frequent use.
Electrical Specifications
Key Electrical Ratings
660 V
Rated Insulation Voltage
10 A
Heating Current
6 kV
Impulse Voltage
Contact Performance
| Metric | Value |
|---|---|
| Insulation Resistance | ≥50MΩ |
| Contact Resistance | ≤25mΩ |
| Withstand Voltage | AC 2.5kV/min |
Mechanical Specifications
Mechanical & Electrical Life
- Pushbutton Mechanical Life: 3,000,000 cycles
- Emergency Stop Mechanical Life: 300,000 cycles
- Standard Electrical Life (Pushbutton): 500,000 cycles
Environmental and Compliance
Operating Environment
- Operating Temperature: -5°C to +55°C
- Storage Temperature: -25°C to +70°C
- Protection Grade: IP65
- Pollution Grade: 3
- Certifications
- CEISO 9001RoHSULIEC 60947-5-1
