Continuous Vertical Elevator for Boxes
This continuous elevator is designed for lifting and conveying box-type components. It utilizes a chain-driven system with load-bearing plates for repeated cycles of lifting and returning.
Technical Specifications
Product Overview
Continuous Vertical Lifting Solutions
These continuous vertical elevators are designed for high-efficiency lifting and conveying of box-type components in industrial packing lines. Utilizing a four-closed-chain drive system with integrated load-bearing plates, they facilitate seamless multi-level transport through repeated cycles of entering, lifting, and exiting. Available in Z-type and C-type configurations, these systems integrate easily with automatic control roller conveyors for intermittent box feeding.
Technical Performance
Performance Metrics
| Model Type | Lifting Height | Max Loading | Max Speed |
|---|---|---|---|
| Z-type | >1000mm | <2000kg | <40m/min |
| C-type | >1500mm | <500kg | <30m/min |
Operational Features
Working Principle
- Four closed chain drive system
- Load-bearing plates installed at fixed intervals
- Four-stage cycle: Entering, Lifting, Exiting, and Returning
- Automatic control roller conveyor at entrance for intermittent feeding
- Vertical lifting mechanism for multi-level operation
Design & Construction
- Construction Details
- Robust Steel FrameIntegrated Roller ConveyorSafety GuardrailsMulti-level StructureStainless Steel Components
Application Scope
End-of-Line Solutions
- Box-type component conveying
- Packing industry automation
- Palletizing system integration
- Stereoscopic warehouse transport
Compliance & Quality
Certifications
ISO 9001:2000Quality Management System Certified
