Continuous Inkjet Printer
This continuous inkjet printer is designed for non-contact printing of variable data. It features a user-friendly interface, stainless steel enclosure, and printhead with flexible conduit.
Technical Specifications
Overview
CX16F Continuous Inkjet Printer
The CX16F is a professional-grade continuous inkjet printer designed for reliable, high-speed industrial coding and marking. It features a brand-new hydraulic system, a user-friendly interface, and supports one-button start/stop control for efficient operation. With the ability to handle Chinese, English, logos, and symbols, it is a versatile solution for printing variable data such as batch numbers and date codes.
Technical Specifications
Operating Environment
- Ambient Temperature: 5-40°C
- Humidity: 30-95% (non-condensing)
- Altitude: 0-2000m
- Dimensions
- 320mm x 420mm x 545mm
- Weight
- 28 kg
- Power Supply
- 100-240VAC ±10%, 50Hz/60Hz
- Rated Current
- 3 A
Printing Capabilities
Performance Metrics
660 chars/sec
Print Speed
2 lines
Max Print Lines
Character Matrix Options
5x57x516x1016x16
- Print Features
- Timing and countingBold (up to 9x)Variable data4-directional printingMessage delay
System & Software
- Compliance
- CEIEC 61000-4 EMC
- Input Methods
- English and Unicode Input Methods
Consumables & Accessories
Available Ink Colors
- Black
- Blue
- Red
- Green
- UV Ink
Optional Accessories
- Handheld printhead bracket
- Conveyor belt
