Product Overview
High-Efficiency Composite Spring Cone Crusher
This advanced cone crusher is engineered for superior performance in medium and fine crushing operations across the mining, aggregate, and construction industries. It features a robust design that balances dynamic cone speed, stroke, and crushing chamber geometry to maximize primary pass rates up to 65%. The inclusion of a spring-based safety system and hydraulic adjustment mechanisms ensures reliable, continuous operation even when processing hard materials with a compressive strength of up to 320MPa.
Key Features
- Advantages
- High crushing ratioLow energy consumptionUniform product sizeOverload protectionHydraulic chamber cleaningFiller-free mantle design
Technical Specifications
Model Specifications
| Model | Max Feeding (mm) | Capacity (t/h) | Power (kW) | Weight (kg) |
|---|---|---|---|---|
| XRY1200C | 180 | 110-250 | 132 | 16,000 |
| XRY1200Z | 80 | 80-180 | 132 | 16,000 |
| XRY1400C | 235 | 210-530 | 220 | 25,000 |
| XRY1400Z | 215 | 200-500 | 220 | 25,000 |
| XRY1650C | 260 | 265-580 | 250 | 35,000 |
| XRY1650Z | 240 | 240-550 | 250 | 35,000 |
| XRY1680C | 300 | 330-750 | 280 | 50,000 |
| XRY1680Z | 200 | 270-600 | 280 | 50,000 |
Industry Applications
Suitable Industries
- Metallurgy
- Mining
- Chemical industry
- Cement production
- Construction
- Refractory materials
- Ceramics
