Compact Rice Harvester
This compact harvester is designed for efficient rice harvesting in diverse field conditions. Its features include a tracked chassis, cutting mechanism, conveying system, and threshing unit for separating grains from stalks.
Technical Specifications
Overview
Compact Rice Harvester
This compact rice harvester is specifically engineered for challenging terrain, including hilly lands, regions with numerous rivers, and narrow rural roads. Designed for efficiency and reliability, it features a crawler-type chassis for superior maneuverability and a riding-type operator position. With its robust 195F diesel engine and advanced filtration system, it ensures high harvesting efficiency while minimizing impurity ratios.
Technical Specifications
Dimensions
2,740 mm
Length
1,320 mm
Width
1,600 mm
Height
- Machine Weight
- 480 kg
Performance
- Rated Feeding Amount
- 0.9 kg/s
- Operation Speed
- 0.4-0.8 m/s
- Productivity
- 0.06-0.1 hm²/hour
Engine & Mechanics
Chassis Type
Crawler-typeRiding-type
- Engine Model
- 195F Diesel Engine
Features
Key Features
- Full feeding mechanism
- Automatic walking
- New type filter structure
- Decreased impurity ratio
- High reliability
Application
- Suitable Terrain
- Hilly landHillsRiver regionsNarrow roads
