Co-Extrusion Laminating Machine, 1500mm Web Width
This co-extrusion laminating machine applies multiple layers of plastic or rubber onto substrates. It features precise controls and multiple extruders for strong bonding across packaging, textile, and industrial applications.
Technical Specifications
Overview
Advanced Co-Extrusion Laminating Solution
This high-performance co-extrusion laminating machine is designed for precision coating and laminating, integrating advanced electrical, pneumatic, and mechanical systems. It features dual extrusion units and specialized shaping systems to deliver consistent, high-quality production for packaging materials. Engineered for automation and reliability, the machine offers an efficient, low-maintenance solution for processing non-woven fabrics, BOPP, and EPE rolls.
Performance Metrics
Design Speed
100 m/min
Max Speed
Max Extruding Capacity
260 kg/h
Capacity per unit
Technical Specifications
Coating Specifications
| Parameter | Value/Range |
|---|---|
| Coating Width | 1000 - 1500 mm |
| Coating Thickness | 0.01 - 0.25 mm |
| Evenness Degree | ±5% |
| Peel Off Strength | 3-5 N/30mm |
- Compatible Materials
- Non-wovenBOPPEPEPECPEEVA
Machine Construction
Physical Dimensions
- Dimensions: 12500 x 7200 x 4430 mm
- Total Weight: 25000 kg
Screw & Barrel Details
- Diameter: 100mm
- L=33D
- Material: 38CrMoAl
- Surface Treatment: Hardening and Nitrogen Treated (NT)
- Power Consumption
- 185 kW
Control Systems
Automation & Control
PLC ControlledServo Motor RectifyMagnetic Powder Tension ControlDigital Temperature Control
