Chili Color Sorting Machine
This chili color sorting machine utilizes a full-color CCD camera to detect subtle color variations and identify small defects. It ensures high sorting accuracy with a belt-type structure, reducing material breakage and preventing collisions.
Technical Specifications
Overview
Advanced Chili Sorting Solution
This high-performance conveyor belt sorting machine is engineered for the precision processing of various chili types, including fresh, dried, and pickled varieties. Utilizing advanced full-color CCD camera technology and intelligent AI photo capture, it effectively identifies and removes impurities, discolored chilies, and stems. The belt-type design ensures gentle material handling to minimize breakage while delivering superior sorting accuracy and consistency for high-volume production lines.
Technical Specifications
Throughput
1.5 T/H
Min Capacity
2 T/H
Max Capacity
- Model
- HSL2-512
- Sorting Accuracy
- 99.98 %
- Number of Ejectors
- 512
- Power Consumption
- 7.5 Kw
- Voltage
- 200V (50Hz)
- Air Pressure
- 0.6-0.8 MPa
Physical Dimensions
- Dimensions (L x W x H)
- 4288 x 2320 x 2400 mm
- Weight
- 1800 Kg
Key Features
Advanced Technology
- Full-color CCD camera with 5400 pixel resolution
- Intelligent AI photo capture
- Real-time image display monitoring
- Optimized carryover ratio (8:1)
- Long-life LED lighting system
- Sorting Capabilities
- Whole ChiliStem RemovalSeed SortingColor SortingShape Sorting
