Technical Specifications
Overview
High-Efficiency Automotive Condenser
This automobile air conditioning condenser is engineered for superior heat exchange and cooling performance. Featuring a parallel flow design with aluminum tubes and fins, it maximizes surface area for optimal thermal management. Built with durable materials and precise fittings, it ensures long-lasting reliability and resistance to environmental corrosion in various vehicle applications.
Key Metrics
Core Dimensions
627 mm
Core Width
425 mm
Core Height
16 mm
Core Thickness
Vehicle Compatibility
Compatible Vehicles
| Model | Engine/Variant | Year Range |
|---|---|---|
| Nissan Rogue | 2.5L I4 | 2008-2013 |
| Nissan X-Trail (T31) | 2.0 DCI | 2007-Present |
Technical Identifiers
Reference Numbers
- OEM: 92100JG000
- DPI: 3680
- NISSENS: 3750
- TS No: 88-73030
Design & Construction
Certifications
CCC
- Construction Features
- Parallel Flow DesignAluminum TubesHigh-Density FinsIntegrated Receiver DrierCorrosion Resistant
Logistics
- Packaging Dimensions
- 730 x 42 x 471 mm
